P61 Intelligent Circuit System Analyzer | Professional 9–30V Diagnostic Probe
The P61 is a high-performance electrical tool engineered for speed and precision. Despite its sleek 154mm body, it provides the advanced data necessary to analyze the circuit with laboratory-level detail. Featuring a 0.96-inch TFT color screen, the P61 eliminates the guesswork of traditional test lights by providing real-time numerical data for voltage, resistance, and frequency.
Comprehensive Diagnostic & Analysis Suite
Versatile Voltage Testing: Effortlessly switch between DC Voltage measurement (0–70V) and Alternating Voltage detection, allowing for the analysis of both steady power supplies and complex sensor signals.
Component Activation & Jumper Functions: Safely power up motors, lights, and relays directly from the probe. The built-in jumper lead function allows you to test ground and power connections instantly.
Deep Circuit Analysis: Beyond simple continuity, the P61 features a wide Resistance range (1Ω – 200KΩ) and Frequency testing (10Hz – 20KHz), making it ideal for verifying the health of modern automotive sensors and PWM-controlled components.
Short-Circuit & Ground Tracing: Quickly identify and track short circuits or poor ground connections that cause intermittent electrical gremlins.
Diode & Continuity Intelligence: Verify the integrity of fuses, switches, and diodes with audible and visual feedback, ensuring a fast and accurate repair workflow.
Safety & Professional Build
Intelligent Protection Suite: To safeguard both the tool and the vehicle's sensitive ECUs, the P61 includes an automatic overcurrent circuit breaker (trips at >8A) and integrated overheat protection.
High-Contrast TFT Display: The 160 × 80 resolution color screen provides clear visibility of critical data, ensuring you can read results in low-light engine bays or bright outdoor environments.
Rugged & Ergonomic Design: Crafted from durable ABS material and weighing only 0.258 kg, the P61 is built for all-day use in the demanding conditions of automotive workshops and construction sites.
Universal Application: Whether you are working on a 12V passenger car, a 24V heavy truck, or marine electronics, the P61 delivers stable and reliable performance across all platforms.
Technical Specifications
Feature | Specification |
Model | P61 Circuit System Analyzer |
Operating Voltage | 9V – 30V |
Voltage Range | 0 – 70V (DC) |
Frequency Range | 10 Hz – 20 KHz |
Resistance Range | 1 Ω – 200 KΩ |
Screen Type | 0.96-inch TFT Color |
Weight | 0.258 kg |
Protections | Overcurrent (>8A) & Overheat |
The Efficient Choice for Mobile & Workshop Techs
The P61 proves that you don't need a bulky workstation to accurately analyze the circuit. By consolidating a multimeter, frequency counter, and component activator into one slim device, the P61 empowers you to find faults faster and with greater confidence.
Take your electrical diagnostics to the next level with the P61—the compact, high-precision analyzer built for modern vehicle systems.
