B02-KD Wireless Diagnostic Scanner

US$17.50Price
Quantity

The B02-KD is a high-performance, mini-sized adapter designed to bring professional wireless diagnostic capabilities to your smartphone or tablet. Powered by the industry-leading

PIC18F25K80 main control chip. This device provides a stable, high-speed connection to your vehicle's ECU.


What sets the B02-KD apart is its advanced voltage flexibility; it is engineered to support both 12V and 24V systems, making it a reliable solution for gasoline and diesel passenger cars, light trucks, and commercial vehicles alike.


Key Performance Features


  • Dual-Voltage Support (12V/24V): Unlike standard scanners, the B02-KD is compatible with a wider range of vehicles, from everyday sedans to heavy-duty commercial trucks equipped with OBD II systems.

  • Pro-Grade PIC18F25K80 Chipset: Experience faster data refresh rates and superior protocol handling. This high-speed chip ensures that your wireless diagnostic sessions are lag-free and accurate.

  • Ultra-Compact "Invisible" Design: At just 49mm, the B02-KD features a "plug-and-forget" form factor. It stays securely in the OBD II port without obstructing legroom or vehicle operation.

  • Full 9-Protocol Coverage: Supports all standard communication protocols, including SAE J1850 (PWM/VPW), ISO9141-2, and modern CAN bus systems, ensuring broad compatibility across US and European markets.

  • Seamless Mobile Integration: Effortlessly pair the device with popular diagnostic apps on your mobile device to view live data and clear codes from the palm of your hand.


Core Capabilities


  • Fault Code Management: Instantly read and clear Diagnostic Trouble Codes (DTCs) to identify engine issues and reset the "Check Engine" light.

  • Live Stream Monitoring: Track real-time engine metrics such as RPM, fuel trim, and coolant temperature while the vehicle is in motion.

  • I/M Readiness Check: Verify emissions status with a single tap to ensure your vehicle is ready for its annual inspection.

  • Freeze Frame Analysis: Access a snapshot of vehicle data at the exact moment a fault occurred for precise troubleshooting.


Technical Specifications

Component

Specification

Main Control Chip

PIC18F25K80 (Industrial Grade)

Wireless Protocol

Bluetooth 2.0 / 4.0 (Compatibility varies by app)

Operating Voltage

9V – 36V DC (Supports 12V & 24V Systems)

Operating Current

~35mA

Standby Current

~25mA

Operating Temperature

-40°C to 85°C

Protocol Support

All 9 Standard OBDII Protocols

Indicator Lights

Power / OBD / Bluetooth Status

Housing Material

Industrial Grade ABS/PC

Packaging & Deployment


The B02-KD is optimized for retailers and large-scale deployment, available in box or static bag packaging with a standard packing quantity of 200 units per carton.


From personal DIY repairs to commercial fleet maintenance, the B02-KD provides the ultimate wireless diagnostic link for any vehicle. Add this versatile tool to your inventory today.
